Description
Features:
- Pad spacing is 2.54mm (.1″) – just like a breadboard
- Dual power rails on the top and bottom of the board, plus a bonus set of power rails down the middle
- Special side traces that allow you to connect the top, middle, and bottom power rails
- Thirty columns of connections just like a 400 point breadboard
- Twelve extra sets of horizontal pads on the side of the board, allowing additional parts or interfacing to external devices
- Boxes on the front of the board to document your project name, date, and version
- A box on the back of the board keep change notes or other documentation.
ProtoPCB 400 Specifications:
Number of tie points (solder pads): 546
Number of horizontal 5-tie point terminals: 60
Number of vertical 5-tie point terminals: 12
Pad drill hole diameter: 40 mil (1.016mm)
Pad diameter 70 mil (1.778mm)
Pad spacing: 2.54mm (.1″)
Trace width: 60 mil (1.524mm)
Surface finish: HASL(with lead)
Hookup Wire Specifications:
Gauge: 24AWG (.51mm)
Conductor strand: Solid
Conductor material: Copper, Annealed Tinned
Temperature range: -20°C ~ 105°C
Color: white or yellow depending on availability
Note: You’ll need a soldering iron and a few other tools.
Click here to see Brian’s tool recommendations.
Front of ProtoPCB 400
Back of ProtoPCB 400
